• CSH-T10

    CSH-T10

    SPECIFICATIONS

    Electrical

    • Current rang: 1A AC, DC
    • Voltage rating: 50V AC/ max.
    • Temperature range:-25°C~+85°C
    • Insulation resistance: 100MΩMin
    • Dielectric Withstanding Voltage: 500V AC/ min.
    • Contact Resistance: 20MΩ/ max.


    Material

    • Terminal maetrial: Phosphor Bronze/ Tin-plated
    • Wire Range: 28 to 32AWG

    PDF

CSH-T10
